Do you feed different types of livestock? Need to grind fast? Our hammer mills allow you the flexibility to change micron size results on the fly with changeable screens. Units are available on a stationary or portable base and with or with a mixing tank in several sizes.
All of the hammer mills feature 4-way reversible knives to get more use out of this common wear item. Choose between a 20 or 26 inch hammer mill size to match the output you desire. A throat magnet prevents metal debris from staying in your feed through processing. A balanced rotor assembly keeps your mill operating smoothly.
Adding an auger feeder makes it easy to load your portable units. The portable units also feature different discharge auger options from a side to side on the units without a tank, choosing mechanical or hydraulic on our smallest grinder mixer, or run with a remote control on our larger units.
105 bushel capacity tank
140 bushel capacity tank
165 bushel capacity tank
215 bushel capacity tank
Choose from various screen sizes to grind your desired size. Check out FAQs to help you pick the screens based on either your livestock or material type.
| Price | $56,772.00 | $71,547.00 | $90,765.00 | $110,750.00 | |
|---|---|---|---|---|---|
| Dimensions | N/A | N/A | N/A | N/A | |
| Capacity of Mixing Tank | 105 bushel (130.7 cu. ft.) | 140 bushel (173.2 cu. ft.) | 165 bushel (205.3 cu. ft.) | 215 bushel (277 cu. ft.) | |
| Width of Mill | 20 in. | 20 in. | 26 in. | 26 in. | |
| Height (with tire size) | 106 in. | 112 in. | 126 in. | 135.25 in. | |
| Overall Length | 170 in. | 170 in. | 175 in. | 197.62 in. | |
| Width with Auger Feeder | 95 in. | 110 in. | 114 in. | 120 in. | |
| Weight with Auger Feeder | 3,540 lbs. | 4,500 lbs. | 5,200 lbs. | 7,200 lbs. | |
| Reversible Hammers | 72 | 72 | 96 | 96 | |
| Screen Area | 600 sq. in. | 600 sq. in. | 780 sq. in. | 780 sq. in. | |
| PTO Drive | 540 RPM | 1000 RPM, 540 RPM | 1000 RPM, 540 RPM | 1000 RPM | |
| Operating Speed of Mill | 2,800-3,000 RPM | 2,800-3,000 RPM | 2,800-3,000 RPM | 2,800-3,000 RPM | |
| Horsepower Requirement | 40-100 hp | 40-100 hp | 80-160 hp | 100-180 hp | |
| Auger Feeder Length | 96 in. | 96 in. | 96 in. | 118 in. | |
| Auger Feeder Diameter | 10 in. | 10 in. | 10 in. | 10 in. | |
| Auger Feeder Type | Hydraulic Trough | Hydraulic Trough | Hydraulic Tube | Hydraulic Tube | |
| Diameter of Mixing Auger | 12 in. flighting/13 in. tube/24 in. base | 12 in. flighting/13 in. tube/24 in. base | 12 in. flighting/13 in. tube/24 in. base | 12 in. flighting/13 in. tube/24 in. base | |
| Discharge Auger Tube Diameter | 8 in. | 8 in. | 10 in. | 10 in. | |
| Discharge Auger Type (lift & swing) | Hydraulic, Mechanical | Hydraulic | Hydraulic | Hydraulic | |
| Unload Auger Reach 60° Angle | 16 ft. 8 in. (10 ft. Tube) | 16 ft. 5 in. (10 ft Tube) | 20 ft. 3 in. (12 ft. Tube) | 21 ft. 6 in. (12 ft. Tube) | |
| Unload Auger Reach 3 ft. Extension 60° Angle | 19 ft. 3 in. (10 ft. Tube) | 19 ft. (10 ft. Tube) | 22 ft. 10 in. (12 ft. Tube) | 24 ft. (12 ft. Tube) | |
| Unload Auger Reach 6 ft. Extension 60° Angle | 22 ft. (10 ft. Tube) | 21 ft. 6 in. (10 ft. Tube) | 25 ft. 5 in. (12 ft. Tube) | 26 ft. 6 in. (12 ft. Tube) | |
| Supplement Hopper Size | 21 x 24 in. | 21 x 24 in. | 21 x 24 in. | 21 x 24 in. | |
| Tires | 10 x 15 8 ply rib implement | 13.5 x 16.1 8 ply high flotation | 13.5 x 16.1 8 ply high flotation | 385-65-R22.5 Implement | |
| Ground Clearance | 10 in. | 10 in. | 13 in. | 17 in. |
| Price | $56,772.00 | $25,597.00 | $18,467.00 | |
|---|---|---|---|---|
| Dimensions | N/A | N/A | N/A | |
| Capacity of Mixing Tank | 105 bushel (130.7 cu. ft.) | N/A | N/A | |
| Width of Mill | 20 in. | 26 in. | 26 in. | |
| Height (with tire size) | 106 in. | 154.73 in | 106 in. | |
| Overall Length | 170 in. | 186.78 in | 83 in. | |
| Width with Auger Feeder | 95 in. | 80.6 in | 68 in. | |
| Weight with Auger Feeder | 3,540 lbs. | 1,600 lbs. | 1,350 lbs. | |
| Reversible Hammers | 72 | 96 | 96 | |
| Screen Area | 600 sq. in. | 780 sq. in. | 780 sq. in. | |
| PTO Drive | 540 RPM | 1000 RPM, 540 RPM | 1000 RPM, Electric | |
| Operating Speed of Mill | 2,800-3,000 RPM | 2,800-3,000 RPM | 2,800-3,000 RPM | |
| Horsepower Requirement | 40-100 hp | 60-80 hp | 40-60 hp | |
| Auger Feeder Length | 96 in. | 96 in. | N/A | |
| Auger Feeder Diameter | 10 in. | 10 in. | N/A | |
| Auger Feeder Type | Hydraulic Trough | Hydraulic Trough | N/A | |
| Diameter of Mixing Auger | 12 in. flighting/13 in. tube/24 in. base | N/A | N/A | |
| Discharge Auger Tube Diameter | 8 in. | 8 in. | 8 in. in Hopper | |
| Discharge Auger Type (lift & swing) | Hydraulic, Mechanical | Mechanical | Mechanical | |
| Unload Auger Reach 60° Angle | 16 ft. 8 in. (10 ft. Tube) | 10 ft. 7 in. (10 ft. Tube) | N/A | |
| Unload Auger Reach 3 ft. Extension 60° Angle | 19 ft. 3 in. (10 ft. Tube) | N/A | N/A | |
| Unload Auger Reach 6 ft. Extension 60° Angle | 22 ft. (10 ft. Tube) | N/A | N/A | |
| Supplement Hopper Size | 21 x 24 in. | N/A | N/A | |
| Tires | 10 x 15 8 ply rib implement | 7.60 x 15 8 ply | N/A | |
| Ground Clearance | 10 in. | 13 in. | N/A |
